FIN6 “FrameworkPOS”: Point-of-Sale Malware Analysis & Internals

Vitali Kremez diving into the FIN6 “FrameworkPOS”, targeting payment card data from Point-of-Sale (POS) or eCommerce systems.

Point-of-Sale (POS) malware remain to be an active threat for financial cybercrime. POS malware targets systems that run physical point-of-sale device and operates by inspecting the process memory for data that matches the structure of credit card data (Track1 and Track2 data), such as the account number, expiration date, and other information stored on a card’s magnetic stripe. Some of the most prolific POS malware lately include the “AlinaPOS”, “GlitchPOS”, and “FrameworkPOS”.

After the credit cards are first scanned in real time, the personal account number (PAN) and accompanying data sits in the point-of-sale system’s memory unencrypted while the system determines where to send it for authorization. During that time, the point-of-sale malware opens up the process memory searching for elements related to credit card information.

The FrameworkPOS malware and related variants are linked to the high-profile merchant breaches in the past including the “MozartPOS” variant involved in the Home Depot intrusion.

POS malware becomes relevant during the Fall shopping season (especially Black Friday) targeting various businesses dealing with live credit card transactions.

Click here to watch the full episode on Dissecting FIN6 “FrameworkPOS”: Point-of-Sale Malware Analysis & Internals

“FrameworkPOS” Malware Internals

One of the more interesting POS malware is called “FrameworkPOS” variants (including the ones dubbed “GratefulPOS” and “MozartPOS”). This malware most recently was internally named as “psemonitor_x64.dll.” FrameworkPOS, also known as TRINITY, was previously linked to the financially motivated hacking collective called FIN6.

 Some of the new FIN6 FrameworkPSS malware variants were spotted by revealing that the group utilizes the 64-bit malware variant with two export functions “workerIntstance” and “debugPoint”.

FIN6 FrameworkPSS malware

Notably, FrameworkPOS malware appears to continue to have low detection ratio according to the detections displayed on VirusTotal (as of September 18, 2019, only 9 out of 66 antivirus engines only treat the malware as suspicious).

For the malware analysis purposes, we also analyze the earlier FrameworkPOS version with the purported “grp1” campaign identifier and contains debug Track 2 data presumably for testing purposes.

The FrameworkPOS main function flow is as follows as psuedo-coded in C++ from creating the “caller” thread to build out the communication protocol and resolve necessary host information.

The excerpt of the main malware functionality is as follows:

    CreateThread(0, 0, (LPTHREAD_START_ROUTINE)caller, 0, 0, 0);

    while ( 1 )
      hSnapshot = CreateToolhelp32Snapshot(2u, 0);
      if ( hSnapshot == (HANDLE)-1 )
        return 0;
      pe.dwSize = 296;

      if ( !Process32First(hSnapshot, &pe) )
        v8 = 0;
        for ( j = 0; j < 0x14; ++j )
          if ( !strcmp(pe.szExeFile, &aWininit_exe[24 * j]) || strstr(byte_592010, pe.szExeFile) )
            v8 = 1;
        if ( !v8 )
          if ( pe.th32ProcessID )
            dwProcessId = pe.th32ProcessID;
            v14 = 1;
            dword_592514 = 0;
            byte_59136B = 0;
            v89 = check_virtualQuery_ex(pe.th32ProcessID, 1);
            if ( v89 )
      while ( Process32Next(hSnapshot, &pe) );
      if ( dword_592410 > 0 )
        _sleep(10000u s);
      v15 -= v11;

The malware proceeds to blacklist certain processes such as “wininit.exe” when approaches memory scraping in order to speed necessary card scan logic.

Credit Card Scraping Logic & Luhn Algorithm

The malware also validates the card information by running the Luhn algorithm for any purported track data that does not begin with digits “4” (VISA), “5” (Mastercard), “6” (Discover), “34″ (AMEX), “37” (AMEX), “36” (Diner’s Club), and “300-305” (Diner’s Club).


The x64 malware version also contains an altered “greedier” version of the Track1/Track2 scanner logic focusing less on static card prefixes and service codes but for any data that looks like Track1/Track2.

FIN6 x64 malware version

FrameworkPOS Data Encoding: XOR & Obfuscation

Throughout its execution, the malware builds some notable strings via xoring the byte section in the loop *(&byte_memory ++) ^= 0x4Dh (via sequence of mov, xor, shl, movsx, and shl calls). Oftentimes, malware coders build string paths to bypass some static anti-virus detection.

FIN6 bypass some static anti-virus detection

Notably, the FrameworkPOS malware obfuscates its stolen data via the hardcoded string and then XOR byte key of “AA” to strings as follows and converts it into hexadecimals adding to snprintf API call:

size_t __cdecl enc_func(char *a1, int a2)
  size_t result;
  unsigned int i;
  for ( len_enc = 0; ; ++len_enc )
    result = strlen(a1);
    if ( len_enc >= result )
    for ( i = 0; i < 69; ++i )
      if ( (unsigned __int8)a1[len_enc] == byte_42E000[i] )
        a1[len_enc] = byte_42E048[i];
    a1[len_enc] ^= AA_key;
    _snprintf((char *)(a2 + 2 * len_enc), 2u, "%.2x", (unsigned __int8)a1[len_enc]);
  return result;

The XOR key function location is as follows:
-------        --------
Address        Function
-------        --------
.text:004030DB notice_write_func
.text:00403847 memory_parser
.text:00403873 memory_parser
.text:004039DE memory_parser
.text:00406C43 computer_name_gen

Command & Control (C2) Protocol

Notably, the FrameworkPOS malware variant leverages hex with 0xAA byte XOR encoding for exfiltrated data with the ping request with the domain name system (DNS) exfiltration protocol.

Credit: @malz_intel

Indicators of Compromise (IOCs):

FrameworkPOS x86:
SHA-256: 81cea9fe7cfe36e9f0f53489411ec10ddd5780dc1813ab19d26d2b7724ff3b38

FrameworkPOS x64:
SHA-256: 7a207137e7b234e680116aa071f049c8472e4fb5990a38dab264d0a4cde126df
